Stand-Alone-Masters
Label: GIN-SAM4
The GIN-SAM4 is a high-performance CPU board by Indel. The powerful master is perfectly suited for high speed applications with complexe an high technical requirements. As a fieldbus master for the Indel GinLink, the GIN-SAM4 controls and coordinate the entire peripheral equipment with a closed-loop bus frequency of up to 64 kHz.
Due to standard interfaces like Gigabit Ethernet, RS232, USB, mPCIe and mSATA, the GIN-SAM4 can be extended with additional modules, such as WLAN, Bluetooths, NFC, GSM/LTE, GPS, graphics cards and SSDs. Thanks to this, the master is ideally equipped for the coming industry 4.0.
Request3 x 1 GBit/s fildbus master
2.2 GHz quad-core PowerPC
Up to 32 GByte RAM
Facts
Interfaces
- 2 × GinLink /
- 3 × GinLink*
- 1 × Gigabit-Ethernet
- 2 × mPCIe
- 1 × mSATA
- 2 × USB 2.0
- 1 × microSD
- 2 × SIO (RS232 / RS485)
- 1 × InfoLink*
Interfaces with Hilscher
EtherCAT, PowerLink, Profinet, Profibus, CANopen, ...
CPU
- PowerPC QorIQ P50xx
- 2.2 GHz Dual-Core / 2.2 GHz Quad-Core
Memory
- 4 GByte SDRAM, DDR3-1600 / 32 GByte SDRAM, DDR3-1600*
- 2 MByte MRAM / 4 MByte MRAM*
- 64 MByte Flash
Operating system
Indel-Realtime-OS (INOS)
Display
Bi-Color E-Paper*
Motion-Control
Max. 256 Achsen
Max. 64 kHz Positions-Update-Frequenz
Dimensions
280 × 46 × 129 mm (h × b × t)
Options
GinLink High-Speed Stand-Alone-Master with quad-core-CPU
Label: GIN-SAM4 | Option: 4x2.2G | Indel-Nr.: 611451440
- 2.2 GHz Quad-Core PowerPC CPU
- 4 × 512 kByte L2 Cache, 2 × 1 MByte L3 Cache
- 1600 MT/s DDR3 RAM 2 x 2 GByte, 2 MByte MRAM
- 2 × GinLink, 2 ×& SIO, 1 × mSATA, 2 × mPCIe
GinLink High-Speed Stand-Alone-Master with dual-core-CPU
Label: GIN-SAM4 | Option: 2x2.2G | Indel-Nr.: 611451420
- 2.2 GHz Dual-Core PowerPC CPU
- 2 x512 kByte L2 Cache, 2 × 1 MByte L3 Cache
- 1600 MT/s DDR3 RAM 2 × 2 GByte, 2 MByte MRAM
- 2 × GinLink, 2 × SIO
GinLink High-Speed Stand-Alone-Master with quad-core-CPU and Multi-Link
Label: GIN-SAM4 | Option: 4x2.2G/ML | Indel-Nr.: 611451442
- 2.2 GHz Quad-Core PowerPC CPU
- 4 × 512 kByte L2 Cache, 2 × 1 MByte L3 Cache
- 1600 MT/s DDR3 RAM 2 × 2 GByte, 2 MByte MRAM
- 1 × GinLink, 2 × SIO, 1 × Powerlink oder EtherCAT, 1 × mSATA, 2 × mPCIe
